Description
SPX Johnson Ultima Bilge Pump 1000 GPH 12 Volt 32-47260 – Automatic Bilge Pump
Sleek, reliable and compact unit with integrated switch (Ultima Switch™) ready to install and run for years of unerring service. Available in 600-800-1000-1250 GPH versions. Voltage 12V DC. All UltimaBilge™ pumps have easy-to-install Dura-Port discharge ports to eliminate stress cracking caused by over-tightened hose clamps. Where applicable, the pumps are delivered, including both a straight and a 90° smooth elbow Dura-Port and a removable check valve. Prewired for easy installation.
Specifications
Johnson Pump Ultima Bilge 1000 gph
- Capacity at 0.9m head (13.6 V): 44 l/min – 700 GPH
- Capacity straight (13.6 V): 64 l/min – 1000 GPH
- Amps: 3.2A
- Fuse size: 5A
- Weight: 0.66kg
- Height: 105mm
- Length: 142mm
- Width: 82mm
- Connection: 3/4”
- Condition: New
- UPC: 9319786412305
Johnson Pump Ultima Bilge 1000 gph
| SKU | Model | Capacity L/m | Capacity gph | Capacity @ 1 metre Head LPM | Capacity @ 1 metre Head GPH | Power (V) | Power (A) | Fuse Size (amps) | Height (mm) | Width (mm) | Outlet Diameter (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 131830 | 600GPH Ultima | 38 | 600 | 32 | 500 | 12 | 2.5 | 5 | 105 | 82 | 19 |
| 131832 | 800GPH Ultima | 51 | 800 | 38 | 600 | 12 | 3 | 5 | 105 | 82 | 19 |
| 131834 | 1000GPH Ultima | 64 | 1000 | 44 | 700 | 12 | 3.2 | 5 | 105 | 82 | 19 |
| 131836 | 1250GPH Ultima | 79 | 1250 | 51 | 800 | 12 | 3 | 3 | 117 | 82 | 28 and 32 |
| 131837 | 1250GPH Ultima | 79 | 1250 | 51 | 800 | 24 | 2 | 5 | 117 | 82 | 28 and 32 |
