BEP Contour Gen 2 Splash Proof Switch Panel – Black 4 switch no fuses CG2-4W 12 or 24 volt
Injection moulded plastic panel with modern contour styling. The switch tray features a rubber mounting gasket and integral cover seal. The cover includes a clear plastic membrane with rubber over-mould allowing the flexibility to operate the switches while providing a clear window for label backlighting.
Red LED indicates systems on. Both grey and blue interchangeable contour wave strips are included and custom colours are available, subject to minimum quantities.
Mounting screws are hidden beneath the cover.Panels can be mounted horizontally or vertically due to the unique label design. A joiner is available for multiple panel installations.
Available in 2, 4 or 6 gang versions with a choice of grey or white facia and with or without fuses. Fused versions have each pair of switches connected to a behind panel mounted AF type blade fuse holder.
Supplied as standard with two position, on/off switches and 113694, 28 piece label set.
Three position switches, momentary switches and label set 113695 (below) are also available.
- Suitable for 12 or 24 Volt systems.
- Switches rated to 16 amp.
- Overall width 63 mm.Cut out width 42 mm.
- Intrusion 25 mm.
- Gang: 4
- Fuses: No
- Overall Length: 119mm
- Cut Out Length: 84mm
- Mount screws 3 mm roundhead.
- Replaceable “clip-on” contour wave.
- Red systems on LEDs.
- Mounting screws are covered by switch cover.
- Moulded gasket on rear of tray seals against mounting surface.
- Labels are LED backlit for easy night time viewing.
- Flexible overshot cover allows for easy switch operation.
- Ribbed seal provides water tight seal with switch cover.
- Unique label design allows it to be read either vertical or horizontally mounted. Supplied with both blue and grey clip on contour wave.
- Label included: SET-G-1.
FAQs
| Item | Content |
|---|---|
| Q1 | Can I use this switch panel in both 12 Volt and 24 Volt systems without any modifications? |
| A1 | Yes. This panel is designed for use with both 12V and 24V DC systems. Ensure your boat’s electrical system voltage matches the panel rating before installation. |
| Q2 | How splash-proof is this switch panel? Can it handle water exposure on my boat? |
| A2 | The panel features a splash-proof design with a rubber mounting gasket and cover seal to protect switches. Avoid direct water jets or submersion. |
| Q3 | Are the switches easy to operate with wet hands, and will I see the labels at night? |
| A3 | Yes — the switch cover has a flexible rubber membrane allowing operation when wet. A clear window provides backlighting for labels and red LED indicators show system status. |
| Q4 | Do I need special tools or skills to install the panel? |
| A4 | Basic tools like a screwdriver are required. Because it involves electrical connections and fuse holders, have someone familiar with marine electrical systems perform or check the installation for safety. |
| Q5 | What if I want more switches or different colours? |
| A5 | The panel comes in 2-, 4-, or 6-gang versions with grey or white facias. Joiners are available to connect multiple panels. |
| SKU | Facia Colour | Gang | Fuses | Overall Length (mm) | Cut Out Length (mm) |
|---|---|---|---|---|---|
| 113756 | Black | 2 | No | 71 | 36 |
| 113757 | White | 2 | No | 71 | 36 |
| 113761 | Black | 2 | Yes | 71 | 36 |
| 113762 | White | 2 | Yes | 71 | 36 |
| 113766 | Black | 4 | No | 119 | 84 |
| 113767 | White | 4 | No | 119 | 84 |
| 113771 | Black | 4 | Yes | 119 | 84 |
| 113772 | White | 4 | Yes | 119 | 84 |
| 113776 | Black | 6 | No | 167 | 132 |
| 113777 | White | 6 | No | 167 | 132 |
| 113781 | Black | 6 | Yes | 167 | 132 |
| 113782 | White | 6 | Yes | 167 | 132 |
Gang: 4 Fuses: No Overall Length: 119mm Cut Out Length: 84mm
