Lewmar Vertical Anchor Windlass – V700 Kit 320W 12V

$1,831.20 inc GST

or 4 payments of $457.80 with Wizit learn more

Lewmar Vertical Anchor Windlass – V700 Kit 320W 12V

Pay by  Add to cart.

In stock

SKU: 154300 Category:

UPC: 743683302930

Condition:  New

In stock

Please call to check on stock before ordering.



Lewmar Vertical Anchor Windlass – V700 12 Volt

The V700 is one of the most attractive and durable windlasses available. The above deck housing features 100% 316 grade stainless steel construction to create an attractive sleek, low profile design.
The V700 is supplied with a combination rope/chain gypsy with the ability to accept 6mm, 7mm and ¼” short link chain together with 12mm medium lay three strand or eight plait nylon rope. Simple power up, power down push button operation and two unique built-in features (motor protection and anchor lock), make this an ideal all around winch.


• 100% 316 grade stainless steel deck unit
• Low profile design
• Dual direction motor
• Combination rope/chain gypsy
• IP67 rated motor casing
• Fall-safe anchor lock
• Fast line speed
• Impact-resistant motor cover
• For boats up to 10m
• 5 year warranty

Standard Inclusions:

154486  Guarded remote up/down rocker switch

154504 Dual solenoid pack

154510 Circuit breaker panel mount 35A

SP15156248 Clutch release handle


154466 Grey down foot switch with closed cover
154468 Grey up foot switch with closed cover
154470 Stainless steel down foot switch with closed cover
154472 Stainless steel up foot switch with closed cover

Watts: 320 Volts Std: 12 Chain Std (mm): 6/7 Rope (mm): 12 Max Pull (kg): 320 Work Load (kg): 79 Max Chain Speed (m/min): 25 Suits Decks (mm): 10-70 Weight (kg): 6.5 Boat Size (m): 6-10
