Description
VETUS Heavy Duty Waterlock in 55L – Black / HPW102
- Suitable for Ø 102, 127 and 152 mm internal hose diameters.
- Special composite blend (NAVIDURIN®) is capable of handling temperatures up to 260 ºC.
- High capacity waterlift design providing complete security for your engine.
- Excellent sound attenuation with minimal back pressure.
- Rotating body and hose connections for easy installation.
- With integrated mounting plate.
- HPW is equipped with 2 drains of G 1/4 internal thread to simplify
access with twin engine installation. - Temperature sensor is optional.
- CAPACITY: 55 Liters
- COLOUR: BLACK
- INLET DIAMETER: 102 mm
- OUTLET DIAMETER: 102 mm
- LENGTH A: 788 mm
- INTERNAL WIDTH B: 380 mm
- OVERALL WIDTH C: 795 mm
- HPW127 55L / BLACK / 127mm Inlet & Outlet Diameter
- HPW152 55L / BLACK / 152mm Inlet & Outlet Diameter
- HPW127152 55L / BLACK / 127mm Inlet & 152mm Outlet Diameter
Made of the special blended composite NAVIDURIN – which is temperature resistant up to 260ºC – these Heavy Duty waterlocks outperform standard GRP materials by 170%.
The same applies for the thermal resistance to deformation under pressure.
The HPW series is perfect for applications where the system is put to the test such as commercial or coastguard vessels.
The ability to handle extreme conditions combined with the rotating bodies and hose connections makes the HPW series an economical alternative to high priced and high-end custom made solutions.
SPECIFICATIONS
OTHER HPW AVAILABLE:
(See complete specifications on the table below.)
| PART NUMBER | CAPACITY (L) | COLOUR | INLET / OUTLET DIAMETER (Ø D/Ø d) | LENGTH (A) | INTERNAL WIDTH (B) | OVERALL WIDTH (C) |
| HPW102 | 55 | BLACK | 102mm/102mm | 648mm | 380mm | 950mm |
| HPW127 | 55 | BLACK | 127mm/127mm | 648mm | 380mm | 950mm |
| HPW152 | 55 | BLACK | 152mm/152mm | 648mm | 380mm | 950mm |
| HPW127152 | 55 | BLACK | 127mm/152mm | 648mm | 380mm | 950mm |
OVERALL PRODUCT SIZE (L/W/H): 450mm x 820mm x 880mm
NOTE – Please call us to check availability & leadtimes prior to ordering as not all Vetus items are carried in stock.
Waterlock High Performance 102 in/out 880x820x450
