ST-Blade Battery Terminal Mount Fuse Block Kit

BLUE SEA – ST Blade Battery Terminal Mount Fuse Block Kit / BS-5024

Original price was: $109.90.Current price is: $79.83. inc GST

or 4 payments of $19.96 with Wizit learn more

BLUE SEA – ST Blade Battery Terminal Mount Fuse Block Kit / BS-5024

Pay by  Add to cart.

On Backorder

ENQUIRY!
Add to wishlist
Compare
SKU: BS-5024 Category:

UPC:

Condition:  New

Out of Stock

NOTE - Please call us to check availability & leadtimes prior to ordering as not all Blue Seas items are carried in stock.

Description

Description

BLUE SEA – ST Blade Battery Terminal Mount Fuse Block Kit / BS-5024

Easily add 4 fused circuits to the terminal of a battery.

Provides power to new accessories in your boat or vehicle.

HIGHLIGHTS

  • Mounts on the battery terminal stud.
  • Screw terminals for securing wires.
  • Nylon insulated ring terminals included for each screw terminal.
  • Accepts small format circuit labels.
  • Insulating cover meets ABYC/USCG insulation requirements.
  • Ignition Protected–meets ISO 8846 and SAE J1171 for use in a gasoline engine compartment.
  • Includes a 4-circuit negative busbar.
  • Includes write on labels.
  • Includes four 16-14 AWG and four 12-10 AWG Nylon insulated ring terminals.

SPECIFICATIONS

  • PART NUMBER: BS-5024
  • CIRCUITS: 4
  • MAXIMUM AMPERAGE: 100A per block / 30A per circuit
  • MAXIMUM VOLTAGE: 32V DC
  • BUS MATERIAL: Tin-Plater Copper C11000
  • MOUNTING HOLE: 3/8″ (M10) Stud
  • SCREW TERMINAL TORQUE: 18 in-lb (2.03 Nm)
  • SCREW TERMINAL TYPE: #8-32
  • WEIGHT 0.23 kg (0.50 lb)

OVERALL DIMENSIONS (LENGTH x WIDTH x HEIGHT): 194mm x 203mm x 49mm
