Description
Jabsco Deckwash Pump Kit – Hotshot 4 HD 15LPM 60 PSI 12 Volt Q401J-118N-3A
The NEW Heavy Duty (HD) HotShot washdown pump kits offer robust construction and high performance.
These new modern design pumps now have a 4-chamber quad diaphragm and heavy-duty wider diameter motor with a powder-coated shell, cast aluminium end bells and lower housing – to improve pressure capability and offer longer life and exceptional performance.
The Jabsco Hotshot 4.0 HD automatic deck washdown kit supplies a constant saltwater flow with quiet operation.
High pressure 60 PSI jet is ideal for removing mud from anchoring hardware and blasting decks and fi shing platforms clean with ease.
Additional or different size snap-in port kits are available. The Jabsco Hotshot ParMax HD4 12v deck wash pump kit includes a 4 chamber diaphragm pressure pump for exceptional performance delivering up to 15.1 L/min at 60 PSI.
Extremely reliable high flow and high-pressure deckwash pump ideal for removing mud from anchoring hardware and blasting your deck and fishing platform clean.
Kit includes:
- 1 x HotShot HD4 Washdown Pump
- 2 x 1/2″ ( 13mm ) straight hosebarbs
- 2 x 3/4″ ( 19mm ) straight hosebarbs
- 1 x 3/4″ GHT fittings (for direct connection to HoseCoil USA threaded hose)
- 1 x 90° 20 mesh quick connect strainer
- 1 x Deluxe trigger nozzle and quick connect hose adapters
- 1/2″ (13mm) Crimp Style Quick Connect
- 3/4″ (19mm) US GHT Quick Connect
Product Specifications:
- Model number: J20-238
- Voltage: 12v
- Open flow: 4GPM ( 15 L/min )
- Shut off pressure: 60 PSI ( 4.1 Bar )
- Maximum current draw: 11.2A
- Recommended fuse size: 20A (not included)
- Motor design: Brushed, permanent magnet TENV
- Pumphead upper housing material: Fiber-reinforced polypropylene
- Diaphragm: Co-moulded TPV
- Check valves: EPDM
- Maximum inlet pressure: 30PSI ( 2.1 Bar )
- Fluid temperature range: 32°F – 140°F (0°C – 60°C)
- Dry self-priming capability: 8ft max ( 2.4m max )
- Certifications: CE, ISO8846, RCM
- Ingress protection: IPX6
- The motor is ignition protected & has thermal overload protection
- Warranty: 3 years
Product Features:
- Co-moulded diaphragm technology for long life and durability
- HD model featuring heavy-duty, motor and cast aluminium lower housing which allow for long life, even at high pressures
- Efficient and quiet operation
- Integrated, sealed pressure switch for on-demand operation
- Self-priming allows for installation versatility
- Can run dry without damage
- Self‐Priming
- Quick connect ports for ease of installation, servicing, and maintenance
- Vibration dampening mounting feet
- A plastic housing protects the motors from corrosion.
- Provides exceptional performance in an economical footprint
- Intermittent Duty- Thermally protected.
Jabsco washdown / deck wash pump kit range:
- J20-238 – 12v – 60psi – 15.1 L/min
- J20-239 – 24v – 60psi – 15.1 L/min
- J20-262 – 12v – 60psi – 15 L/min with hose
- J20-248 – 12v – 70psi – 18.9 L/min
- J20-252 – 12v – 70psi – 22.7 L/min
- J20-253 – 24v – 70psi – 22.7 L/min
- J20-254 – 12v – 70psi – 22.7 L/min with hose
Replaces Jabsco Deckwash Kit – Par-Max 4 15LPM 60 PSI 12 Volt 32605-7001
